Seven Key Factors to Consider When Selecting Protective Garments

Protective garments play a critical role in keeping workers safe from hazardous substances. They achieve this goal by keeping hazardous materials out of the clothing and away from the worker. There are regulatory requirements for chemical protective coveralls which specify their safety features and properties for use in different applications. Nevertheless, there are still performance differences between garments that meet the same regulatory requirements.

Several factors differentiate one chemical protective coverall from another, including the material used, the design of the garment, and the quality of manufacturing. Choosing which protective clothing is the best solution for each application requires an assessment of the safety needs as well as the garment features that meet those needs. Here are seven key factors to consider when selecting chemical protective coveralls:





1. Material

There are three common material types used for protective garments.

  • Spunbond Meltblown Spunbond (SMS) fabrics, which is a trilaminate non-woven fabric.
  • Microporous Film (MPF) is also a non-woven laminate fabric
  • Tyvek® is nonwoven fabric consisting of ultrafine continuous flashspun polyethylene fibers

DuPont™ Tyvek® fabric offers an ideal balance of protection, durability, comfort and contamination control versus SMS and MPF materials and therefore acts as a breathable barrier against particles and infective agents. For instance, permeation rate is an important factor when evaluating protective clothing against liquid and gaseous chemicals and is a key measure when comparing the performance of garments. A generic permeation test is of limited value because different liquid chemicals may permeate a coverall at different rates.

Some manufacturers provide tables with more detailed information about permeation properties for a variety of chemicals. This table show the Actual Breakthrough time (BT Act) when the first molecule passes through the fabric for each type of protective clothing they produce. They also show the BT 1.0 (which is the time taken to reach 1 mg/cm2/min of permeation) as required by European Standards. Other parameters shown may include the highest permeation rate known as the Steady State Permeation Rate (SSPR) and the minimum detectable permeation rate known as the Minimum Detectable Permeation Rate (MDPR).





Key factors to consider when selecting protective garments are: material, linting properties, anti-static treatment, zipper design, ease of movement, stitching and gluing, and quality control.




Choosing which protective garment is the best solution for each application requires an assessment of the safety needs as well as the garment features that meet those needs.

2. Linting properties

One of the challenges with chemical protective coveralls is the contamination of products due to particle shedding. These particles can come from the workers or from the protective garments themselves. Different materials have different characteristics when it comes to particle shedding. DuPont™ Tyvek® 500 fabric, for example, is inherently low linting and abrasion resistant.

Particle shedding is particularly vital in industries like pharmaceutical manufacturing where foreign particles can contaminate a product causing substantial losses to the manufacturer. Specifically, the Cleanroom environment of pharmaceutical companies has strict regulations for particle shedding and must be tightly controlled to prevent contamination.





3. Anti-static treatment

While many industries require the use of protective garments, some industries are more hazardous than others. For example, some chemical protective coveralls are worn in explosive environments, which have the dual risks of exposure to hazardous materials and the possibility of explosion.  In all cases, PPE must be dissipative and shall be worn in combination with conductive or antistatic shoes to provide the necessary earthing for a good dissipation of a possible electrostatic charging.

European Standards for performance classification of protective clothing against chemicals are covered by EN 14325. However, this standard does not require electrostatic properties. EN 1149-5 covers this additional requirement. Companies purchasing protective garments for EX zones must therefore ensure that the coverall they purchase meets both these European Standards, as a minimum.




<span class="fontsize12">Tyvek® offers an ideal balance of protection, durability, comfort and contamination control versus SMS and MPF materials and therefore acts as a breathable barrier against particles and infective agents</span><br><br><span class="fontsize28"><b>4. Zipper Design</b></span>
The zipper is a point of vulnerability for chemical protective coveralls because liquids and solid particles could migrate through the zipper and come into contact with the worker. However, several features can help to prevent this possibility.

  • Zippers made with liquid-tight DuPont™ Tyvek® fabric are far superior to textile zippers as they do not allow the migration of particles or liquids through the zipper.
  • Auto-lock zippers do not allow the zipper to open by itself while wearing the garment thus preventing an accidental opening where hazardous materials could pass through.
  • Diagonally sewn zipper flaps direct liquid drops away from the coverall seams.







5. Ease of movement

Whenever the wearer of a protective coverall moves, they could expose weaknesses in the garment by stretching them to the point of tearing or by creating a gap between the garment and the worker. Simple motions like squatting or moving the head are typical examples. This challenge can be overcome through design features.

Protective clothing made using 3D designs with gussets give more freedom of movement than flat 2D designs and avoid tears that could occur when squatting. A three-piece hood design helps to minimise risk of exposure by ensuring the hood moves with the head. This design is more effective than a two-piece hood, which does not move when the wearer turns their head.





6. Stitching and gluing

Every stitch on a protective garment makes a hole in the clothing where dust or liquid can accumulate, especially at the seam of the waist elastic. The type of seam significantly influences its protective capability. External seams offer higher levels of protection from ingress of foreign materials than internal seams. Other options include taping. Overtaping a stitched seam makes it even tighter and may even offer protection against the permeation of chemicals. But only a tight seam will maintain the garment’s integrity and protect workers from hazardous materials. If the seams are not overtaped, it is recommended to reduce the number of stitched seams. Using a glued-in waist elastic rather than a stitched-in waist elastic preserves the benefit of better fit while eliminating the need for a very long stitched seam in the back.





Protective garments play a critical role in keeping workers safe from hazardous substances. The European PPE regulation and the CE certification for chemical protective garments require that the manufacturers implement strict quality controls.





7. Quality Control

Protective garment manufacturers must have strict quality control measures to ensure that every coverall coming off the production line meets the specifications and will protect workers from hazards in accordance with their rating. The best manufacturers have quality systems with multiple layers of protection:

  • The first level of quality assurance is achieved through checks performed by the production facility itself.
  • The second level of quality assurance is achieved through checks performed by resources from the same company but from outside the production facility.
  • A final level of quality assurance is achieved by inviting third party resources from outside the company to check the quality of protective garments. These tests are normally unannounced to increase their effectiveness.

The European PPE regulation and the CE certification for chemical protective coveralls require that the manufacturers implement strict quality controls and are therefore a guarantee of protection and performance for the wearer of such garments, unlike non-CE certified white coveralls.

DuPont™ Tyvek® garments have excellent performance as protective clothing for workers in various industries. This performance stems from the properties of Tyvek® material, the design and manufacturing of the garments, as well as the strict quality control procedures we adopt.

Find out more about DuPont™ Tyvek® protective garments at: dpp.dupont.com
