Tyvek / Tyvek® 500 HV

TY0125SHV00

Tyvek® 500 HV

DuPont™ Tyvek® 500 HV. Collared coverall. Ergonomic-protective design. Stitched external seams. Elasticated wrists and ankles. Elasticated waist (glued-in). Tyvek® zipper and flap. Fluorescent orange with grey reflective bands.




Hover over image to zoom

CAT III

T5

T6

ENISO 20471

EN 1073-2

EN 1149-5

EN 14126

Name Description
Full Part Number TY0125SHV00
Fabric/Materials TYVEK® 500 HV
Design Collared coverall with elastics
Seam Stitched (external)
Color Orange
Sizes SM, MD, LG, XL, 2X, 3X

FEATURES & PRODUCT DETAILS

DuPont™ Tyvek® 500 HV. Collared coverall available in fluorescent orange with silver grey reflective bands for day and night visibility, available in sizes SM to 3X. Robust yet lightweight. Mandarin collar, elasticated wrists and ankles as well as glued-in waist elastic. Ample crotch area for freedom of movement. Large, easy-to grasp zipper puller.
Tyvek® 500 HV garments are mainly composed of flash spun polyethylene, providing an ideal balance of protection, durability and comfort. Thanks to their nonwoven structure, they are permeable to both air and water vapour, yet repel water-based liquids and aerosols. They offer an excellent barrier against fine particles and fibres, are ultra-low linting and antistatically treated on the inside. Their bright fluorescent orange colour combined to silver grey reflective bands make them highly visible during the day as well as in the night (when exposed to a light source).
Applications for Tyvek® 500 HV garments include rail, road, mining, waste handling, undergrounds, ports, airports and construction.

  • Certified according to Regulation (EU) 2016/425.
  • Chemical protective clothing, Category III, Type 5-B and 6-B. (1956)
  • EN 14126 (barrier to infective agents), EN 1073-2 (protection against radioactive contamination), EN ISO 20471 (High Visibility Clothing, Class 3), RIS-3279-TOM Issue 1
  • Antistatic treatment (EN 1149-5) - on inside
  • Stitched external seams.
  • Very low inward leakage thanks to optimised design
  • Tyvek® auto-lock zipper and zipper flap for increased protection..
  • All-in-one solution: high-visibility (to the highest class), chemical, biological and antistatic protections in one coverall
  • Durability & breathability of Tyvek®
  • Ideal when working in dangerous environments, darkness or poor weather conditions

SIZES

Fabric & Permeation/Penetration Data

Physical Properties

Data relating to mechanical performance of the fabrics used in DuPont chemical protective clothing, listed for the selected garment according to the test methods and relevant European standard, if applicable. Such properties, including abrasion and flex-cracking resistance, tensile strength and puncture resistance can help in the assessment of protective performance.

Property Test Method Typical Result EN
Abrasion Resistance 7 EN 530 Method 2 >100 cycles 2/6 1
Basis Weight TAPPI T460 47 g/m2 N/A
Colour. N/A (598) Fluorescent Orange (RIS-3279-TOM) N/A
Flex Cracking Resistance 7 EN ISO 7854 Method B >15000 cycles 4/6 1
Puncture Resistance EN 863 >10 N 2/6 1
Surface Resistance at RH 25%, inside 7 EN 1149-1 < 2,5 • 109 Ohm N/A
Surface Resistance at RH 25%, outside 7 EN 1149-1 No antistatic treatment N/A
Tensile Strength (MD) DIN EN ISO 13934-1 >30 N 1/6 1
Tensile Strength (XD) DIN EN ISO 13934-1 >30 N 1/6 1
Trapezoidal Tear Resistance (MD) EN ISO 9073-4 >10 N 1/6 1
Trapezoidal Tear Resistance (XD) EN ISO 9073-4 >10 N 1/6 1
  •  According to EN 14325
  •  According to EN 14126
  •  According to EN 1073-2
  •  According to EN 14116
  •   According to EN 11612
  •  Front Tyvek ® / Back
  •  Based on test according to ASTM D-572
  •  See Instructions for Use for further information, limitations and warnings
  •  Larger than
  •  Smaller than
  •  Smaller than or equal to
  •  Not Applicable
  •  Standard Deviation

GARMENT PERFORMANCE

COMFORT

PENETRATION AND REPELLENCY

BIOLOGICAL BARRIER

HIGH VISIBILTY CLOTHING
